Co-NETIC® AA 屏蔽片材

Co-NETIC® AA 屏蔽片材的概况 -

Co-NETIC^® AA 完全退火板用于需要高衰减的地方，它提供完全退火，可用于屏蔽应用，用于平坦屏蔽，如盖子、面板、门、板、墙壁和平坦表面。通常不需要进一步退火，事实上我们不建议重新退火，因为这可能会导致结构退化。

完全退火板已在质量控制的退火环境中按照严格的规格完全退火，该环境构建了晶粒结构，这是最终屏蔽性能所需的重要机械性能。完全退火板提供从 0.014 in/0.36 mm 到 0.080 in/2.00 mm 厚度规格。

符合 ASTM A753 合金 4 和 MIL-N-14411C Comp 1。
Co-NETIC® AA 屏蔽片材的优势 +

➤ 完全退火，屏蔽性强
➤ 表面光滑，无熔渣毛刺
➤ 根据您的需求切割成更小的坯料
Co-NETIC® AA 屏蔽片材的性能 +

Co-NETIC® AA 屏蔽片材的指标 +

产品型号	厚度	宽度	长度
CP014-30-14	0.014 in	30.00 in	14.00 in
CP014-30-14	0.36 mm	762.0 mm	355.6 mm
CP014-30-29	0.014 in	30.00 in	29.00 in
CP014-30-29	0.36 mm	762.0 mm	736.6 mm
CP014-30-59	0.014 in	30.00 in	59.00 in
CP014-30-59	0.36 mm	762.0 mm	1499.0 mm
CP020-30-14	0.020 in	30.00 in	14.00 in
CP020-30-14	0.50 mm	762.0 mm	355.6 mm
CP020-30-29	0.020 in	30.00 in	29.00 in
CP020-30-29	0.50 mm	762.0 mm	736.6 mm
CP020-30-59	0.020 in	30.00 in	59.00 in
CP020-30-59	0.50 mm	762.0 mm	1499.0 mm
CP025-30-14	0.025 in	30.00 in	14.00 in
CP025-30-14	0.64 mm	762.0 mm	355.6 mm
CP025-30-29	0.025 in	30.00 in	29.00 in
CP025-30-29	0.64 mm	762.0 mm	736.6 mm
CP025-30-59	0.025 in	30.00 in	59.00 in
CP025-30-59	0.64 mm	762.0 mm	1499.0 mm
CP030-30-14	0.030 in	30.00 in	14.00 in
CP030-30-14	0.76 mm	762.0 mm	355.6 mm
CP030-30-29	0.030 in	30.00 in	29.00 in
CP030-30-29	0.76 mm	762.0 mm	736.6 mm
CP030-30-59	0.030 in	30.00 in	59.00 in
CP030-30-59	0.76 mm	762.0 mm	1499.0 mm
CP040-30-14	0.040 in	30.00 in	14.00 in
CP040-30-14	1.00 mm	762.0 mm	355.6 mm
CP040-30-29	0.040 in	30.00 in	29.00 in
CP040-30-29	1.00 mm	762.0 mm	736.6 mm
CP040-30-59	0.040 in	30.00 in	59.00 in
CP040-30-59	1.00 mm	762.0 mm	1499.0 mm
CP050-30-14	0.050 in	30.00 in	14.00 in
CP050-30-14	1.27 mm	762.0 mm	355.6 mm
CP050-30-29	0.050 in	30.00 in	29.00 in
CP050-30-29	1.27 mm	762.0 mm	736.6 mm
CP050-30-59	0.050 in	30.00 in	59.00 in
CP050-30-59	1.27 mm	762.0 mm	1499.0 mm
CP062-30-14	0.062 in	30.00 in	14.00 in
CP062-30-14	1.58 mm	762.0 mm	355.6 mm
CP062-30-29	0.062 in	30.00 in	29.00 in
CP062-30-29	1.58 mm	762.0 mm	736.6 mm
CP062-30-59	0.062 in	30.00 in	59.00 in
CP062-30-59	1.58 mm	762.0 mm	1499.0 mm
CP080-30-14	0.080 in	30.00 in	14.00 in
CP080-30-14	2.00 mm	762.0 mm	355.6 mm
CP080-30-29	0.080 in	30.00 in	29.00 in
CP080-30-29	2.00 mm	762.0 mm	736.6 mm
CP080-30-59	0.080 in	30.00 in	59.00 in
CP080-30-59	2.00 mm	762.0 mm	1499.0 mm
